AKASH Industrial Roots Blower Compressors/Blowers are positive displacement units,whose pumping capacity is determined by size, operating speed and pressure conditions. It employs two impellers mounted on parallel shafts, rotating in opposite direction within a casing closed at the ends by side plates. As the impellers rotate, air is drawn into one side of the casing and forced out of the opposite side. The differential pressure developed, therefore, depends upon the resistance of the connected system. The Blowers, being positive displacement type, do not develop pressure within the casing but the discharge pressure depends upon the system resistance / back pressure. A pair of precise machined alloy steel, hardened and ground timing gears to transmit power and motion between parallel shafts to minimize the vibration & noise. The sealing arrangement of akash blower’s is designed in such a way to ensure 100% oil free air delivery.
Description
AKASH Industrial Roots Blower Compressors/Blowers are positive displacement units,whose pumping capacity is determined by size, operating speed and pressure conditions. It employs two impellers mounted on parallel shafts, rotating in opposite direction within a casing closed at the ends by side plates. As the impellers rotate, air is drawn into one side of the casing and forced out of the opposite side. The differential pressure developed, therefore, depends upon the resistance of the connected system. The Blowers, being positive displacement type, do not develop pressure within the casing but the discharge pressure depends upon the system resistance / back pressure. A pair of precise machined alloy steel, hardened and ground timing gears to transmit power and motion between parallel shafts to minimize the vibration & noise. The sealing arrangement of akash blower’s is designed in such a way to ensure 100% oil free air delivery.
Features of Industrial Roots Blower
- 100% oil free air delivery
- Factory engineered, Factory guaranteed, superior product
- Alloy steel hardened and ground timing gears
- Oil splash lubrication
- Anti-friction bearings
- Rigid one piece CI casing & end plates
- Horizontal & Vertical configurations available
- Air Cooled & Water Cooled design available
- Dynamically balanced rotor shaft assembly (Grade 6.3 or 2.5 as per ISO:1940)
- Large inlet & outlet connections for minimal loss
- Improved volumetric efficiency and reduced operating temperatures
- Performance testing as per standard test procedure based on BS:1571-2 and ISO:1217
- All blowers are manufactured on state of the art, imported CNC machines, machined to close tolerances with high degree of accuracy on profile machining, ensuring high volumetric efficiency
- All major components are interchangeable.
SCOPE OF SUPPLY (INDUSTRIAL ROOTS AIR BLOWERS)
AKASH Blowers are available as package units, ready to install or base blower units for replacement.
- A) Bare Blower:
- Blower
- Suction & Discharge Inter-Connecting Pipeline/Companion Flanges
- Blower Pulley
- First Oil/Grease Fill
- B) Blower With Standard Accessories (Pressure Duty) Including Water Cooled Blowers:
- Blower
- Common Motor & Blower Base Frame with Motor Rails
- Belt Guard /Coupling Guard
- Suction Air Filter
- Suction Silencer
- Pressure Gauge
- Safety Relief Valve(Spring Loaded type)
- Pulleys & Vee Belts / Coupling
- ICP with Companion Flange
- O&M Manual
- First Oil/Grease Filled
- C) Additional Accessories (Available As Per Requirements):
- NRV
- Discharge Silencer
- Anti Vibration Pad
- Electric Motor
- SS Bellows
- Acoustic Hood
- Foundation Bolts
- D) Blower with Standard Accessories (Vacuum Duty):
- Blower
- Common Motor, Blower Base Frame with Motor Rails
- Belt Guard / Coupling Guard
- Vacuum Gauge
- Vacuum Relief Valve
- Pulleys & Belts/Coupling
- ICP with Companion Flange
- O&M Manual
- First Oil/Grease Filled
- E) Blower with Standard Accessories(Gas Duty):
- Blower
- Common Motor, Blower Base Frame With Motor Rails
- First Oil/Grease Filled
Note: Above mentioned accessories are standard, may vary as per client job requirement and as per application.
Frequently Asked Questions (FAQs)
Q1. What is an industrial roots blower used for?
Roots blowers are used in water treatment, material conveying, dust collection, and aeration applications.
Q2. What is the lifespan of a roots blower?
With proper maintenance & Instructions, our blowers can run efficiently for 10 years.
Q3. Do you provide installation and AMC services?
Yes, we provide complete after-sales support including installation, training, and AMC.
Q4. Is your blower oil-free?
Yes, as the sealing arrangement is designed in such a way that there is no leakage from oil chamber to compression chamber, hence it delivers 100% air delivery.
